HIMA X-CPU 01 985210211 是一款高性能的处理器模块，属于HIMax系统内的关键数据处理部件。以下是关于这款处理器模块的详细信息和特点：

1. 产品概述：
• 型号：HIMA X-CPU 01 985210211
• 类型：高性能处理器模块
• 系统兼容性：用于HIMax系统内进行数据处理
2. 主要功能：
• 数据处理：作为HIMax系统的核心部件，处理多达32个用户程序，并执行所有中央功能，包括通信。
• 冗余功能：支持多达3个附加处理器模块的冗余功能，提高系统可靠性和容错性。
• 通信功能：通过安全以太网进行通信，确保数据的安全传输。
• 事件管理：创建并存储CPU事件，同时存储I/O模块创建的事件。
3. 安全特性：
• TÜV认证：该模块已通过TÜV认证，适用于SIL 3以下的安全相关应用，符合IEC 61508、IEC 61511和IEC 62061、Cat. 4 (EN 954-1) 和 PL e (EN ISO 13849-1)等安全标准。
• 故障处理：在出现故障时，能够停止用户程序并将变量重置为初始值，或将处理器模块重置为安全状态并报告CPU状态。
• 自检功能：硬件自检确保模块的持续稳定运行，同时与I/O模块的安全通信功能也增强了系统的整体安全性。
4. 其他特性：
• 地址分配：具有详细的地址分配方案，用于存储参数、测量值以及其他信息。
• 错误处理：在通讯有错误时，可实行重试操作，最大次数为4次。
• 响应超时：节点发送请求后，响应超时的时间定为1S，超时则进行错误处理。
5. 应用环境：
• 该处理器模块适用于需要高性能数据处理和严格安全要求的应用环境，如工业自动化、过程控制等领域。

HIMA X-CPU 01 985210211 is a high-performance processor module that is a key data processing component in HIMax systems. Here are the details and features of this processor module:

Product Overview:

Model: HIMA X-CPU 01 985210211

Type: High performance processor module

System compatibility: Used for data processing in the HIMax system

Main functions:

Data processing: As a core component of the HIMax system, it handles up to 32 user programs and performs all central functions, including communications.

Redundancy: Supports redundancy for up to three additional processor modules to improve system reliability and fault tolerance.

Communication function: Secure Ethernet is used for communication to ensure the safe transmission of data.

Event management: Create and store CPU events as well as events created by I/O modules.

Security features:

TUV Certification: The module is TUV certified for safety-related applications up to SIL 3 and complies with safety standards such as IEC 61508, IEC 61511 and IEC 62061, Cat.4 (EN 954-1) and PL e (EN ISO 13849-1).

Troubleshooting: In case of failure, the ability to stop user programs and reset variables to initial values, or reset processor modules to a safe state and report CPU status.

Self-check function: Hardware self-check ensures the continuous and stable operation of the module, while the secure communication function with the I/O module also enhances the overall security of the system.

Other features:

Address assignment: Has a detailed address assignment scheme for storing parameters, measurement values, and other information.

Error handling: When there is a communication error, you can retry the operation for a maximum of four times.

Response timeout: After a node sends a request, the response timeout duration is set to 1S. If the response timeout occurs, an error is processed.

Application environment:

The processor module is suitable for applications that require high performance data processing and strict safety requirements, such as industrial automation, process control, etc.
